dsh-file-attach

dsh-file-attach

English · 简体中文

dsh-file-attach is a host-and-web DSH plugin for attaching local files to a conversation. It accepts any non-empty file within the configured size limit, extracts supported documents into model-readable text, and stores the original outside the session workspace. PNG, JPEG, WebP, and GIF images take DSH's native vision path when the selected model explicitly supports image input; otherwise the plugin uploads them for OCR and an optional text description.

Unsupported binary formats can still be uploaded and saved into the workspace, but their prompt extract is only a “no text extractor” note.

What the plugin adds

• Page-wide drag and drop, image paste handling, a multi-file picker, and an Attach files… entry in DSH's / menu.
• English and Chinese labels, status text, and upload error notifications.
• 1 MiB sequential chunk uploads with aggregate progress and extraction status.
• A composer-aligned dock showing plugin-uploaded files and their sizes.
• Extractors for text/code, PDF, DOCX, XLSX, PPTX, Jupyter notebooks, and raster images.
• Model-aware routing between DSH native vision and plugin OCR/extraction.
• Hidden model context: the model receives the extract, while the rendered conversation shows only a compact attachment header.
• Four model-facing tools for notebook inspection, PDF page OCR, image description, and saving the original file.
• Session-scoped vault storage, filename/path sanitization, upload admission limits, partial-upload cleanup, and a persisted-extract lookup endpoint.

Requirements and installation

• Node.js 22.13 or newer.
• DSH with the Cordis host and web client plugin system.

Install the npm package into the web profile:

npx @deepseek-ai/dsh plugin --profile web add --allow-build=tesseract.js @lucasxingg/dsh-file-attach

Until the package is on npm, install from GitHub instead:

npx @deepseek-ai/dsh plugin --profile web add --allow-build=tesseract.js github:LucasXingg/dsh-file-attach

pnpm 10+ blocks dependency build scripts. OCR uses tesseract.js, which has one, so the first add without --allow-build=tesseract.js fails with ERR_PNPM_IGNORED_BUILDS. That is not a successful install.

If you already hit that error, allow the script in the profile and re-run:

# ~/.dsh/profiles/web/pnpm-workspace.yaml
allowBuilds:
  tesseract.js: true

Do not run add dsh-file-attach. That unscoped npm name is a different plugin (dsh-file-attach@1.0.0) and will not provide drag-and-drop or /attach.

Alternatively, download the package from GitHub Releases or clone this repository, run npm ci in the checkout, then add that directory:

npx @deepseek-ai/dsh plugin --profile web add /path/to/dsh-file-attach

Restart dsh web and refresh the browser after installation. The running GUI does not hot-install the bundle. cordis.patch.yml adds one file-attach row; the package exposes both the host entry (lib/index.js) and the generated browser entry (lib/client.js).

Attaching files

Input	Actual behavior
Drag and drop	A capture-phase page-wide listener claims every file drop. With no active session it still prevents the browser default, logs a console warning, and discards the files without a toast.
Paste	The plugin claims a paste only when it contains at least one supported raster image. It routes every file in that paste and appends any plain clipboard text to the draft. A file-only paste with no raster image is left to DSH.
/ menu	Select Attach files… to open a multi-file picker with no file-type filter.
Dock Add button	Opens the same picker. The dock is rendered only after a plugin upload has started, so use drop, paste, or the / menu for the first attachment.
/attach <id>	Reuses a known attachment reference. In the same page lifetime it can submit the cached extract; after reload it sends a degraded ID hint because filename/size metadata is not persisted.

On the plugin upload path, empty files and files larger than maxFileBytes are rejected in the client and again by the host. Native-vision image admission is owned by DSH instead. Plugin uploads are accepted only for a live session. If the composer is busy (its phase is neither plain nor claimed), plugin uploads are refused with a notification.

Files routed to the plugin from one batch start independently; the client does not queue them or pre-check maxConcurrentUploads. The dock combines all in-flight files into one aggregate progress bar. On each file's final request, the label switches to extraction while progress is held at an approximate 95%. After extraction, the reference chip is inserted at the end of the draft with up to two revision-guarded attempts. If insertion fails, the client shows an error, but the completed file remains in the vault and ready dock.

Image routing

Only PNG, JPEG, WebP, and GIF are classified as raster images.

1. The client asks the host about the currently selected provider/model.
2. The host resolves model metadata.
3. visual: true is returned only when inputModalities explicitly includes image.
4. Visual-model images are handed to DSH's native composer image rail.
5. Unknown, failed, or text-only model lookups fall back to plugin upload, OCR, and optional description.
6. If the native composer image API rejects the batch, the plugin also falls back to its upload path.

Native-vision images are not copied into this plugin's vault, do not receive a 12-character attachment ID, do not appear in its dock, and cannot be used with the attach_* tools. In a mixed batch, native images follow the vision path while all other files are uploaded by the plugin.

Supported extraction

Input	Detection	Extract sent to the model
Text and source	text/* or a known extension such as txt, md, csv, json, html, css, js, ts, py, go, rs, java, c/cpp, sh, yaml, toml, sql, and others	UTF-8 text; invalid byte sequences are replaced.
PDF	.pdf or application/pdf	Merged text layer. A PDF with no text layer produces a note directing the model to attach_pdf_ocr_page.
Word	.docx or the DOCX MIME type	Raw text from Mammoth. Legacy .doc is not supported.
Excel	.xlsx or the XLSX MIME type	Sheet headings and tab-separated cell values. Legacy .xls is not supported.
PowerPoint	.pptx or the PPTX MIME type	Slide headings and text recovered from slide XML. Legacy .ppt is not supported.
Jupyter notebook	.ipynb	Every cell's type and source; for non-display text outputs, only the final two lines per cell are included in the initial extract.
Raster image	PNG, JPEG, WebP, or GIF by MIME type or extension	Format/dimensions when detectable, Tesseract OCR, and an optional short LLM description. This path is used only when native vision is unavailable or fails.
Other binary	Anything else	A note naming the unsupported extension and MIME type. The original remains available to attach_save.

Every extract is capped at maxExtractChars. Truncation is marked in the text and in the persisted extract metadata. Extraction errors do not discard a completed upload: the original and an error extract are kept so the agent can still use attach_save.

Image OCR and automatic description

The OCR worker is reused and recreated when ocrLanguages changes. With explainImages: true, the plugin also attempts a best-effort one-shot caption through the first available LLM provider and model. Captioning requires both the llm and attachments services; missing services, missing model identity, timeouts, and failures leave OCR intact and add no fatal upload error.

What the model and user see

For a successful plugin upload, the submitted model text is:

[attached file "report.pdf" (2.4 MB) id=a1b2c3d4e5f6]
----- extracted content -----
…extracted text…
----- end -----

The browser removes the extract fence from rendered conversation text and shows only the attachment header. The underlying submitted message still contains the extract. Vault paths are never put into the prompt.

The 12-character lowercase hexadecimal id is the preferred identifier for all tools. A filename also works when exactly one upload in the current session's vault has that basename; duplicate names require the ID.

Attachment metadata is held in browser memory. After a page reload, a restored reference does not recover the original filename and size, so it degrades to:

[attached file id=a1b2c3d4e5f6 — extraction unavailable after reload; use attach_* tools with id a1b2c3d4e5f6]

The original and extract.json still exist in the vault, and the tools can resolve the original by ID.

Model-facing tools

All four tools return text. Domain errors are reported as tool errors. They operate only on plugin-uploaded files in the current session vault.

attach_notebook_output

Returns one complete Jupyter cell: its index/type, source, every text output, errors/tracebacks, and omitted non-text MIME bundle names and byte sizes.

{"id":"a1b2c3d4e5f6","cell":0}

• id — attachment ID or a unique notebook filename.
• cell — zero-based index; non-integers and out-of-range values fail.
• The attachment must have an .ipynb filename.

attach_pdf_ocr_page

Rasterizes one PDF page at 2× scale and OCRs it with ocrLanguages.

{"id":"a1b2c3d4e5f6","page":1}

• id — attachment ID or a unique PDF filename.
• page — one-based positive integer.
• The attachment must have a .pdf filename.
• Returns (no OCR text on page N) when recognition is empty.

attach_describe_image

Starts the configured describeProvider subagent with a custom prompt.

{"id":"a1b2c3d4e5f6","prompt":"List every visible UI label"}

• id — attachment ID or a unique filename.
• prompt — required non-empty instruction.
• Requires the DSH subagent service. When the attachment service is available, the original bytes are passed as an image; otherwise the subagent receives only the filename alongside the prompt.
• The implementation does not enforce an image extension, although the tool is intended for PNG/JPEG/WebP/GIF uploads.
• Returns the subagent's text output, (empty description), or a tool error when the subagent cannot complete.

attach_save

Copies the untouched original from the vault into the session workspace.

{"id":"a1b2c3d4e5f6","path":"docs/report.pdf"}

• id — attachment ID or a unique original filename.
• path — destination relative to the session workspace.
• Parent directories are created automatically.
• Paths resolving to the workspace root or outside it are rejected.
• An existing destination file is overwritten.
• Returns the normalized workspace-relative destination path.

Host HTTP surface

These routes support the bundled web client; they are not a separate public remote API.

Method and route	Purpose
POST /api/dsh-file-attach/upload	Opens or continues a chunk upload; validates the live session, metadata, limits, chunk headers, and final byte count; extracts and persists the completed file.
POST /api/dsh-file-attach/abort	Best-effort removal of an in-progress upload directory by upload ID.
GET /api/dsh-file-attach/extract	Returns persisted extract.json for a valid upload ID in a live session.
GET /api/dsh-file-attach/config	Returns client-visible limits and supported raster MIME types.
GET /api/dsh-file-attach/vision	Resolves whether the selected/current session model explicitly accepts image input.

Upload requests carry metadata in x-session-id, x-file-name, x-file-type, x-file-size, x-chunk-index, x-chunk-count, and, after the first chunk, x-upload-id headers. Chunks for each upload are serialized by the host. An individual request body is capped at maxFileBytes + 1 MiB.

The config response exposes maxFileBytes, maxFilesPerMessage, maxConcurrentUploads, vaultDir, maxExtractChars, explainImages, ocrLanguages, and the raster MIME list. It does not expose explainTimeoutMs, describeProvider, or the fixed client chunk size.

Configuration

Edit the config object on the file-attach row in cordis.patch.yml.

Key	Default	Actual effect
maxFileBytes	52428800 (50 MiB)	Per-file admission limit, checked by client and host.
maxFilesPerMessage	20	Reported to the client, but the current client does not enforce a per-message count.
maxConcurrentUploads	20	Maximum open host upload sessions; additional first chunks receive HTTP 429.
vaultDir	file-attach	Subdirectory of $DSH_HOME (or ~/.dsh) containing originals and extracts.
maxExtractChars	80000	Character cap applied to each initial extract.
explainImages	true	Enables best-effort automatic LLM captions on the plugin image path.
ocrLanguages	eng+chi_sim	Tesseract language IDs used for image and PDF-page OCR.
explainTimeoutMs	30000	Abort timeout for automatic image captions.
describeProvider	spawn	Provider passed to attach_describe_image when starting a subagent.

The upload chunk size is fixed in the bundled client at 1 MiB and is not a configuration key.

Storage, cleanup, and security

Plugin uploads are stored at:

$DSH_HOME/file-attach/<sanitized-session-id>/<12-char-id>/
├── <sanitized-original-name>
└── extract.json

If $DSH_HOME is unset, the base is ~/.dsh. vaultDir replaces the file-attach segment. Filenames are reduced to a basename, stripped of control characters and leading dots, trimmed, and capped at 200 characters. Session IDs are reduced to one safe path segment.

Aborted and failed partial uploads are removed best-effort. Abandoned partial uploads expire after 10 minutes and are swept once per minute. Completed uploads are not garbage-collected: removing a composer reference does not delete the original, and ready dock entries have no removal control. Plugin teardown aborts active browser uploads and cleans open host upload sessions.

The routes are same-origin and live-session checks protect upload, extract, and vision operations, but there is no separate bearer credential. The abort and config routes do not require a session header. Bind DSH to 127.0.0.1 unless an authenticated reverse proxy protects it. See SECURITY.md.

Current limitations

• Browser attachment metadata and dock state are not persisted across reloads.
• Reloaded /attach <id> references degrade to an ID hint instead of rehydrating the full extract into the prompt.
• Ready dock entries have no remove control and are not synchronized with removal of composer reference chips.
• maxFilesPerMessage is exposed but not enforced by the current client.
• Completed vault files have no automatic retention or garbage-collection policy.
• Scanned PDFs are not OCRed automatically at ingest; use attach_pdf_ocr_page one page at a time.
• Native-vision images bypass the plugin vault and tools.
• Automatic image captions choose the first available provider/model, not necessarily the conversation's selected model.
• The page-wide drop listener claims any file drop for the active session.
• Without an active session, a drop is consumed and discarded with only a console warning; the localized noSession toast is not currently used.
• Reference chips are appended at the draft end rather than inserted at the caret.
• Legacy Office formats (.doc, .xls, .ppt) have no extractor.
• SVG, BMP, TIFF, and other non-PNG/JPEG/WebP/GIF images do not use OCR or native vision; they follow text detection or unsupported-binary handling.
• OCR behavior depends on available Tesseract language data; automated tests stub the OCR and PDF raster backends rather than exercising real downloads.

Development

npm ci
npm test
npm run build:client
git diff --exit-code -- lib/client.js
npm pack --dry-run

src/client-core.js and src/client-app.js are plain scripts assembled by scripts/build-client.mjs; commit the regenerated lib/client.js whenever either source changes. CI runs the test suite on Node.js 22 and 24 and verifies the generated bundle and release package.

Project layout:

lib/index.js              host routes, limits, lifecycle, and tool registration
lib/extract.js            text, Office, notebook, PDF, image, and OCR extraction
lib/ingest.js             admission, sanitization, vault paths, and model forms
lib/tools.js              attach_* tool definitions
lib/vision.js             current-model visual capability resolution
lib/client.js             generated browser bundle
src/client-core.js        pure browser helpers
src/client-app.js         browser plugin and UI behavior
scripts/build-client.mjs  browser bundle assembly
test/                     node:test suites

Releases and contributing

The npm package name is @lucasxingg/dsh-file-attach (the unscoped name dsh-file-attach is already taken). To publish from a machine logged in as the npm user lucasxingg:

npm whoami   # must print lucasxingg
npm test
npm run build:client
npm publish --access public

Releases follow semantic versioning and are recorded in CHANGELOG.md. A matching v* tag runs tests, verifies the generated client, packs the npm tarball, and publishes a GitHub Release with generated notes.

See CONTRIBUTING.md for development guidance, SECURITY.md for private vulnerability reporting, and LICENSE for license terms.
